Mold Interfaces & InspectionChoose Components Against the Target Press
DME imperial and HASCO metric are component-system options, not automatic regional settings. Confirm locating, ejection, cooling, and electrical interfaces against the target press drawings and approved mold design. SPI classes below are reference classifications, not a tool-life warranty.
Specify required thread and coupler interfaces against the press and plant connections.
Agree the required inspection method, report format, material certificates, and delivery records before the quotation is approved.
Discuss Press Interfaces
Define Tooling AcceptanceConfirm the Requirements in the Contract
If your project specifies an SPI class, share the applicable standard and edition. We can review it with the RFQ; scope, inspection, acceptance, and any tool-life commitment must be confirmed in the written agreement.
Production and tool life
State expected production quantity and the required tool-life target, with operating assumptions where known.
Steel and heat treatment
Specify required steel grades, heat treatment, and the material or process records to be supplied.
Mechanisms and components
List required slides, lifters, inserts, cooling, ejection, and press-interface components.
Trials and maintenance acceptance
Define trial samples, inspection criteria, maintenance scope, and the records needed for acceptance.
Mold Steel SelectionConfirm Material Against Project Requirements
General reference only. This table does not confirm Nodinson stock, certification, or the properties of material used on a project. Verify the selected grade and heat-treatment condition against the supplier's current documentation.
Steel grade
Origin: Confirm supplier and sourceSet finish target and acceptance sample
Assess resin and operating environment
Confirm grade, heat treatment, and documentation against the approved project specification.
SPI Polish & VDI Spark TexturesReference Values for Specification Discussions
These are general finish references, not measured results or a guarantee for a particular mold. Confirm the applicable standard, texture source, and acceptance sample in the project specification.
Polishing approach
Set the cosmetic target and review against an approved sample.
Texture process
Specify texture source, area, and acceptance sample.
DME (Imperial) vs HASCO (Metric)Examples for Press-Drawing Review
DME / imperial and HASCO / metric are component-system options, not geographic defaults. The entries below are a requirements checklist; confirm exact parts and dimensions against the target press drawings, current supplier catalogs, and approved mold design.
| Hardware Parameter | North America (DME Imperial) | Europe & Global (HASCO Metric) | Production Risk / Mitigation |
|---|---|---|---|
| Locating and mounting | DME Specify required dimensions and components | HASCO Specify required dimensions and components | Check against the target press and platen drawings. |
| Cooling connections | DME Specify thread and coupler requirements | HASCO Specify thread and coupler requirements | Confirm compatibility with the plant's hoses and connections. |
| Ejection and guidance | DME Specify pins and guide components | HASCO Specify pins and guide components | Confirm replacement and maintenance requirements. |
| Lifting and clamping | DME Specify lifting and clamping interfaces | HASCO Specify lifting and clamping interfaces | Review against approved handling and press requirements. |
| Electrical and hot runner | DME Specify connectors, controller, and voltage | HASCO Specify connectors, controller, and voltage | Confirm equipment compatibility before design approval. |
Engineering Standards Takeaways (Quick Summary for Buyers & Audits)
Unsure which SPI class or regional fittings suit your press?
Email the target press details, preferred component system, production target, and inspection/report needs. Do not attach confidential CAD before a written NDA is in place.
